SL600AC
The SL600AC gate opener designed for residential use, weight up to 600 Kg and operating distance up to 8 meters.
Compact structure, cost-effective.Built in control board
Keypad / single button interface.
Alarm lamp, Photo beam & safety beam interface.
User can select auto-close function.
Optional for spring limit switch and magnetic limit switch
Manual key release design for emergency purposes.
Automatic stop when hitting obstacle during opening, auto-reverse when hitting obstacle during closing. (Smart version)
Technical Specifications
Model |
SL600AC |
Power supply |
220V, 50Hz; 110V, 60Hz |
Remote control range |
≥30m |
Max. gate weight |
600Kg |
Motor power |
200W |
Output torque |
16N·m |
Work duty |
S2, 15min |
Limit switch |
Spring limit switch or magnetic limit switch |
Remote control mode |
Single button |
Frequency |
433.92MHz |
Output shaft height |
46mm |
Noise |
≤58dB |
Extra remote control |
25 (2 included) |
Environmental temperature |
-20°C~+50°C |
Gate moving speed |
11m/min |
13m/min |
