PY500AC
The PY500AC gate opener designed for residential use, weight up to 500 Kg and operating distance up to 8 meters.
Brushed aluminum shell, novel appearance.Built in control board
Keypad / single button interface.
Alarm lamp, Photo beam & safety beam interface.
User can select auto-close function.
Optional for spring limit switch and magnetic limit switch
Manual key release design for emergency purposes.
Automatic stop when hitting obstacle during opening, auto-reverse when hitting obstacle during closing. (Smart version)
Technical Specifications
Model |
PY500AC |
PY500ACU |
Power supply |
220V, 50Hz |
110V, 60Hz |
Max. gate weight |
500Kg |
Motor power |
180W |
Output torque |
14N·m |
Work duty |
S2, 15min |
Output shaft height |
63mm |
Limit switch |
Spring limit switch
or magnetic limit switch |
Gate moving speed |
11m/min |
Remote control range |
≥30m |
Remote control mode |
Single button |
Frequency |
433.92MHZ |
Noise |
≤60dB |
Extra remote control |
25 (2 included) |
Environmental temperature |
-20°C~+50°C |
Gate moving speed |
12m/min |
