Solar Panel

Portable folding solar panel kits. Compatible with DC gate opener



Technical Specifications:
Item No.: SL10/12V
Mono or Poply: MONO
Maximum power (W): 10W
Maximum power voltage (V):17.3
Maximum power current (A): 0.58
Open circuit voltage (V) :21.2
Short circuit current (A): 0.66
Number of cells (Pcs): 18
Size of module (mm): 340*292*18mm
Brand Name of Solar Cells
Maximum system voltage (V): 715
Temperature coefficients of Isc (%): 0.065+/-0.015%/°C
Temperature coefficients of Voc (%): -(2.23+/-0.1)mv/ °C
Temperature coefficients of Pm (%): -(0.5+-0.05)/ °C
Temperature coefficients of Im (%): +0.1/ °C
Temperature coefficients of Vm (%): -0.38/ °C
Temperature Range :-40°C~+85°C
Tolerance Wattage (e.g. +/-5%): +/-5%
Surface Maximum Load Capacity: 60m/s(200kg/sq.m)
Allowable Hail Load: steel ball fall down from 1m height
Weight per piece (kg): 1.3
Length of Cables (mm): 3000mm
Cell Efficiency (%) :16 %
Module Efficiency (%): 14.5%
Output tolerance (%): +/-3%
Frame (Material, Corners, etc.): Aluminum
Standard Test Conditions:( AM1.5 100mw/cm2 25°C
FF (%): 69%
Packing: 2PCS/ CTN
