Built-in control board, without backup battery.
Intelligent charging system supplied.
MCU is supplied to control the gate opener.
Keypad / single button interface.
Alarm lamp, Photo beam & safety beam interface.
User can select auto-close function.
Electronic limit switch and soft start & slow stop function.
Manual key release design for emergency purposes.
Automatic stop when hitting obstacle during opening, auto-reverse when hitting obstacle during closing.
Solar System compatible


Technical Specifications

Model	DKC300DC
Power supply	240V/50Hz; 110V/60Hz
Maximum gate weight	300Kg
Motor power	24VDC 100W
Output torque	8N·m
Limit switch	Electronic
Gate moving speed	13m/min
Remote control range	≥30meters
Remote control model	Single button
Extra remote control	25 (2 included)
Frequency	433.92MHZ
Work duty	S2 30min
Noise	≤60dB
Working temperature	-20ºC ~ +50ºC
Backup battery	----
